DELAY RANGE

Use the righthand toggle to select a time range for the DELAY knob:

  • delay-low 0 - 400ms
  • delay-mid 0 - 800ms
  • delay-high 0 - 1600ms

Use MIDI, TouchOSC, or the web editor to access a fourth range, 0-3200ms.

By changing the delay time abruptly, the toggle can introduce unique, syncopated rhythms into the feedback path.

DELAY DIVISIONS

Holding [ALT] and adjusting the righthand toggle creates subdivisions within the delay line.

Set up a delay line to observe the effect by either adjusting the DELAY knob or using tap tempo.

  • EIGHTH NOTE
    EIGHTH NOTE
  • DOTTED EIGHTH NOTE
    DOTTED EIGHTH NOTE
  • QUARTER NOTE
    QUARTER NOTE
